APC Smart-UPS 1000VA Tower protects your data by supplying reliable, network-grade power for space constrained business critical applications. A perfect UPS for protecting business critical fileservers (Intel or UNIX based), minicomputers, network switches and hubs, Point of Sale, retail/bank back office and ATM's.
With included PowerChute management software, IT administrators can provide safe system shutdown and advanced UPS management. Connectivity is through serial or USB port. Additional manageability is available through the SmartSlot. With pure sine-wave output, and Intelligent Battery Management ensuring a highly available UPS. The Smart-UPS is a UPS you can count on.
- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Smart-UPS
- Product Type
- Line-interactive UPS
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Plug/Connector Type
- IEC 320-C14
- Receptacle Type
- IEC 60320 C13
- Receptacle Detail
- 2 x IEC 60320 C13
- 8
- Bypass Switch
- Not Provided
- Emergency Power OFF
- Optional
- Power Description
- Load Capacity (VA)
- 1 kVA
- Load Capacity (Watt)
- 670 W
- Input Voltage
- 220 V AC
- Output Voltage
- 240 V AC
- Waveform Type
- Sine Wave
- Surge Energy Rating
- 320 J
- Management
- Alarm
- On Battery
- Low Battery
- Configurable Delay
- Battery Management
- Intelligent Battery Management
- Controls/Indicators
- Status Indicators
LED status display with:
- Load bar-graphs
- Battery bar-graphs
- On Line
- On Battery
- Replace Battery
- Overload
- Interfaces/Ports
- Serial Port
- Yes
- USB
- Yes
- Total Number of Expansion Slots
- 1
- Battery Information
- Battery Characteristics
- Spill-proof, Maintenance-free
- Battery Chemistry
- Lead Acid
- Backup/Run Time (Full Load)
- 6.10 Minute
- Backup/Run Time (Half Load)
- 20.60 Minute
- Hot Swappable
- Yes
- Environmental Conditions
- Maximum Operating Temperature
- 45°C
- Thermal Dissipation
- 100 BTU/h
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Height
- 215.9 mm
- Width
- 170.2 mm
- Depth
- 439.4 mm
- Form Factor
- Tower
- Weight (Approximate)
- 18.82 kg
- Miscellaneous
- Package Contents
- Smart-UPS 1000VA Tower
- Software CD
- Smart UPS signaling RS-232 cable
- USB cable
- User Manual
- Additional Information
- Output Voltage Distortion: Less than 5% at full load
- Crest Factor: Up to 5 : 1
- Replacement battery cartridge quantity: 1
- Units per Pallet: 24
- Adjustable voltage sensitivity
- Adjustable voltage-transfer points
- Automatic restart of loads after UPS shutdown
- Automatic self-test
- Automatic Voltage Regulation (AVR)
- Generator compatible
- Predictive failure notification
- Certifications & Standards
- C-tick
- CE
- EN 50091-1
- EN 50091-2
- GOST
- PCBC
- VDE
- UL 1449
- Software Included
- PowerChute management software
